The more efficient and economical product compare to
normal elevator for disabled and eldery.
Vertical wheelchair lift of shinwoo Frontier Co.,Ltd is more efficient and economicl option than normal elevators. This product does not require any structural changes to the site and takes up only minimal installation space which will help tremendously when it come to those who are having difficulites with stairs such as disabled and elderly.
Video
Product information
| Sortation | Material and specification | |
| Operation type | Rope indirect hydraulic pressure method (fork type) | |
| Rated speed | 7m/min | |
| Rated load | 340Kg | |
| Main power supply | AC 220V single-phase, 60Hz, 30A | |
| Motor | AC 2,2kw, 1720rpm | |
| Elevator | Standard | 950(W) x 1450(D) x 1050(H) |
| Material | Cold low carbon steel pipe / Cold low carbon steel plate | |
| Painting | Powdered painting (color : hammer tone ivory) | |
| Control method | PLC control | |
| Pump | 2.2CC/rev. | |
| Cylinder | ∮ 50 | |
| Pit(PIT) | S Type | 1435(W) x 1480(D) x 150(H) |
| EN Type | 1575.5(W) x 1600(D) x 75(H) | |
| Strokes | S Type | Below S type 2000m |
| EN Type | below 40000mm | |
| MAST Standard | 820(W) x 300(D) x (H) | |
